The Orlando is a PREMIUM model manufactured with 70mm (2-3/4") thick wall logs, with 525 ft² of comfort. A 2 bedroom model with a vaulted ceiling, provides added ceiling height. An ideal cabin, small home, rental unit, additional dwelling unit, or granny flat. The package is delivered to the site and ready to assemble on a concrete slab or wood subfloor. Includes exterior & interior walls, premium double-glazed windows & doors, with hardware and mortised locks, deadbolts & keys plus interior doors with hardware and trims.
This premium model is insulated on the interior using metal brackets to mount 2×4 studs with 3/4" tongue & groove boards applied over the studs. The solid wood of 2 3/4" thick has a thermal mass rating of R-12
Add R-15 insulation and achieve exceptional energy efficiency of R-27. The insulating kit is only 10% of the selling price and includes brackets & T&G cover boards
Tip: Mineral wool insulation is recommended for log construction. It’s impervious to moisture with a higher R-value per inch than fiberglass and is considered a GREEN building material, environmentally friendly insulation
Tip: An extra entry door can be added on request and modify plans without cost providing no added materials are required.
The Orlando can be assembled in 4 days with 3 people and passes structural requirements for building codes. Modifications may be required for earthquake, heavy snow load regions, and hurricane zones.
- Ready to mount on slab or wood subfloor
- (70mm) 2 3/4" Pre-cut numbered exterior walls
- (70mm) 2 3/4" Pre-cut numbered interior walls
- Vaulted ceilings
- Roof purlins (beams)
- Tongue & groove roof boards
- Fascia trims
- PREMIUM double-glazed wood windows
- Entry doors c/w locks, deadbolts, keys
- Window & door trims
- Interior doors c/w hardware
- Threaded steel storm rods for perimeter wall junctions
